A1/A2 Type Cable Glands

  • Size : 20 mm to 90 mm
  • Standard : EN 50262 : 1999
  • Application : Outdoor or Indoor for use with all types of Unarmoured Cable
  • Function : Provide Seal on Outer Sheath of the Unarmoured Cable
  • Material : Brass BS 2874 CZ121 Pb3
  • Optional Threads : METRIC, NPT, BSP, PG or as specified
  • Finish : Brass Finish, Nickel Finish, Chrome Finish or as specified
  • Operating Temp. : Standard seals -20°C to +80°C
  • Accessories : Matching Accessories available like PVC Shrouds, Lock Nuts, Earth Tags, Reducers, Adaptors, etc. as per the requirement

Technical Data

Size Thread Size 'C' Minimum Length
of Thread 'D'		 Cable Range
MM INCH MAX 'A' MAX 'B'
A2 20S 20 3/4 15 10.80 8.80
A2 20L 20 3/4 15 14.70 11.40
A2 25S 25 1 15 16.00 13.00
A2 25L 25 1 15 20.30 17.30
A2 32S 32 1.1/4 15 23.00 20.00
A2 32L 32 1.1/4 15 26.20 24.20
A2 40S 40 1.1/2 20 29.00 26.00
A2 40L 40 1.1/2 20 34.00 29.50
A2 50S 50 2 20 41.00 33.00
A2 50L 50 2 20 45.00 38.00
A2 63S 63 2.1/2 20 51.50 44.00
A2 63L 63 2.1/2 20 56.50 50.00
A2 75S 75 3 20 63.20 56.00
A2 75L 75 3 20 68.50 62.00

Also available in Kit Packaging and also as per the specification

CW Type Cable Glands / CW NPT Type Cable Glands

  • Size : 20 mm to 90 mm S & L
  • Standard : EN 50262 : 1999
  • Application : For indoor or outdooruse with all types of SWA Cable
  • Function : Provide for Environmental Seal in the Cable Outer Sheath,. Also provide mechanical cable retention & electrical continuity.
  • Material : Brass BS 2874 CZ121 Pb3
  • Optional Threads : METRIC, NPT, BSP, PG or as specified
  • Finish : Brass Finish, Nickel Finish, Chrome Finish or as specified
  • Operating Temp. : Standard seals -20°C to +80°C
  • Accessories : Matching Accessories available like PVC Shrouds, Lock Nuts, Earth Tags, Reducers, Adaptors, etc. as per the requirement

Technical Data

Size Thread Size 'C' Minimum Length
of Thread 'D'		 Cable Range
MM INCH MAX 'A' MAX 'B'
CW 20S 20 3/4 10 11.80 17.80
CW 20L 20 3/4 10 14.00 20.80
CW 25S 25 1 10 18.00 24.00
CW 25L 25 1 10 20.30 27.40
CW 32S 32 1.1/4 10 24.50 31.00
CW 32L 32 1.1/4 10 26.50 34.20
CW 40S 40 1.1/2 13 30.40 38.50
CW 40L 40 1.1/2 13 33.20 41.00
CW 50S 50 2 13 40.00 47.00
CW 50L 50 2 13 44.00 53.50
CW 63S 63 2.1/2 14 50.00 59.00
CW 63L 63 2.1/2 13.50 56.00 66.00
CW 75S 75 3 15 63.50 73.00
CW 75L 75 3 15 69.00 79.00
Size Size Minimum Length
of Thread 'D' 		Cable Range
MM THREAD NPT MAX 'A' MAX 'B'
CWNPT 20S 20 1/2" 10 11.80 17.80
CWNPT 20L 20 1/2" 10 14.00 20.80
CWNPT 25S 25 3/4" 10 18.00 24.00
CWNPT 25L 25 3/4" 10 20.30 27.40
CWNPT 32S 32 1" 10 24.50 31.00
CWNPT 32L 32 1" 10 26.50 34.20
CWNPT 40S 40 1.1/4" 13 30.40 38.50
CWNPT 40L 40 1.1/4" 13 33.20 41.00
CWNPT 50S 50 1.1/2" 13 40.00 47.00
CWNPT 50L 50 1.1/2" 13 44.00 53.50
CWNPT 63S 63 2" 14 50.00 59.00
CWNPT 63L 63 2" 13.50 56.00 66.00
CWNPT 75S 75 2.1/2" 15 63.50 73.00
CWNPT 75L 75 2.1/2" 15 69.00 79.00

Also available in Kit Packaging and also as per the specification

E1W Type Cable Glands

  • Size : 20 mm to 90 mm S & L
  • Standard : EN 50262 : 1999
  • Application : For indoor or outdoor use with all types of SWA Cable
  • Function : Provide for Environmental Seal in the Cable Outer sheath. Also, provide mechanical cable retention & electrical continuity
  • Material : Brass BS 2874 CZ121 Pb3
  • Optional Threads : METRIC, NPT, BSP, PG or as specified
  • Finish : Brass Finish, Nickel Finish, Chrome Finish or as specified
  • Operating Temp. : Standard seals -20°C to +80°C
  • Accessories : Matching Accessories available like PVC Shrouds, Lock Nuts, Earth Tag, Reducers, Adaptors, etc. as per the requirement

Technical Data

Size Thread Length A B A/F A/C
20S M20 15.00 12.00 16.00 22.20 24.20
20L M20 15.00 14.00 20.50 27.00 29.50
20/16 M20 15.00 9.00 14.00 22.20 24.20
25S M25 15.00 18.50 24.50 33.50 37.50
25L M25 15.00 20.50 27.50 36.00 40.00
32S M32 10.40 24.30 34.00 43.00 48.50
32L M32 15.00 26.27 34.20 43.50 48.50
40S M40 15.00 29.50 41.50 52.00 58.00
40L M40 15.00 33.00 41.50 52.00 58.00
50S M50 15.00 38.50 47.00 59.00 65.50
50L M50 15.00 44.30 53.20 64.20 71.50
63S M63 20.00 50.20 62.50 73.50 81.50
63L M63 20.00 56.20 65.50 79.50 89.00
75S M75 20.00 62.00 74.00 87.00 97.00
75L M75 20.00 68.00 78.20 97.00 108.00
90L M90 18.50 80.00 91.00 103.50 114.50

Also available in Kit Packaging and also as per the specification

IP 68 Cable Glands


We possess the capability to manufacture up to M90, with a clamping range spanning from 60 to 75 mm. Our design and specifications are flexible, adaptable to meet the unique requirements of our esteemed customers.

Specification: Premium Brass IP68 Universal Cable Gland
Technical Information Material
Body with Lock Nuts Nickel Plated Brass
Insert Polyamide - 6
Sealing Ring Neoprene
O - Ring Perbunan
Additional Features:
  • With Vibration Lock and Strain Relief Protection Class IP 68 - 5 Bar
  • Temperature Range: -300°C to +900°C

Technical Data

Size Clamping Range Thread Length (in mm)
PG-7 2-6.50 6.00
PG-9 3-8.00 6.00
PG-11 4-10.00 6.00
PG-13.5 5-12.00 8.00
PG-16 8-14.00 8.00
PG-21 11-18.00 8.00
PG-29 16-25.00 9.00
PG-36 20-30.00 9.00
PG-42 28-38.00 12.00
PG-48 34-44.00 12.00
M12 2-6.50 6.00
M16 3-8.00 6.00
M20 5-12.00 8.00
M25 11-18.00 8.00
M32 12-21.00 8.00
M40 18-27.00 9.00
M50 27-33.00 9.00
M63 34-48.00 12.00
Cable Glands are suitable for connections provides with flexible cables in:
  • Weather Proof Enclosures
  • Controlling & Liquid Measuring Instrument
  • Control Panels
  • Machineries
  • Limit Switches
  • Medical Equipments
  • Multi Pin Connectors
  • Electric Motors

BW 2 PT Cable Glands

  • Size : 20 mm to 90 mm
  • Standard : BS 6121
  • Application : Dry Indoor, for use with all types of SWA Cable
  • Function : Provide mechanical Cable Retention & Electrical Wire continuity via Armoured Wire.
  • Material : Brass BS 2874 CZ121 Pb3
  • Optional Threads : METRIC, NPT, BSP, PG or as specified
  • Finish : Brass Finish, Nickel Finish, Chrome Finish or as specified
  • Operating Temp. : -80°C to +300°C
  • Accessories : Matching Accessories available like PVC Shrouds, Lock Nuts, Earth Tag, Reducers, Adaptors, etc. as per the requirement

Technical Data

Size Thread Size 'C' Minimum Length
of Thread 'D'		 Cable Range
MM INCH MAX 'A' MAX 'B'
BW 20S 20 3/4 10 13.00 15.50
BW 20L 20 3/4 10 14.00 18.50
BW 25L 25 1 10 20.50 26.00
BW 32L 32 1.1/4 10 27.00 33.90
BW 40L 40 1.1/2 15 33.00 41.50
BW 50S 50 2 15 38.50 47.00
BW 50L 50 2 15 44.00 52.00
BW 63S 63 2.1/2 15 51.00 59.20
BW 63L 63 2.1/2 15 56.50 65.50
BW 75S 75 3 15 63.00 74.00
BW 75L 75 3 15 68.50 79.50
BW 90L 90 3.1/2 20 80.50 91.00

Also available in Kit Packaging and also as per the specification

BW 4 PT Cable Glands

  • Size : 20 mm to 90 mm S & L
  • Standard : BS 6121
  • Application : Dry Indoor, for use with all types of SWA Cable
  • Function : Provide mechanical Cable Retention & Electrical Wire continuity via Armoured Wire.
  • Material : Brass BS 2874 CZ121 Pb3
  • Optional Threads : METRIC, NPT, BSP, PG or as specified
  • Finish : Brass Finish, Nickel Finish, Chrome Finish or as specified
  • Operating Temp. : -80°C to +300°C
  • Accessories : Matching Accessories available like PVC Shrouds, Lock Nuts, Earth Tag, Reducers, Adaptors, etc. as per the requirement

Technical Data

Size Thread Length A B A/F A/C
20S M20 10.00 13.00 18.00 23.50 26.00
20L M20 10.00 14.00 21.00 25.00 28.00
25S M25 10.00 18.00 24.00 31.00 35.50
25L M25 10.00 20.50 27.00 33.00 37.00
32S M32 10.00 27.00 33.50 40.50 45.50
32L M32 10.00 27.00 33.50 40.50 45.50
40S M40 13.00 31.50 39.50 45.50 50.50
40L M40 13.00 33.00 41.50 49.00 55.00
50S M50 13.00 39.50 48.50 56.50 63.50
50L M50 13.00 44.50 54.50 62.50 70.50
63S M63 14.00 50.20 59.20 68.80 77.00
63L M63 13.50 56.50 65.50 76.00 86.00
75S M75 15.00 63.50 72.00 84.00 94.50
75L M75 15.00 69.50 78.50 90.00 101.00
90S M90 20.00 76.00 85.00 100.00 111.20
90L M90 18.00 78.40 90.50 103.00 115.00

Also available in Kit Packaging and also as per the specification

Cable Glands Accessories

  • Application : Brass lock nuts re traditional components used in fastening glands to the gland plate & as they are identical material to the gland, corrosion effects are minimal.
  • Function : Standard with ISO metric thread. To secure only brass cable glands to a gland plate.
  • EMC : With ISO metric thread with cutting edges to cut through paint layers or powder coatings, for optimum contact.
  • Material : Brass BS 2874 CZ121 Pb3 Steel, Galvanized Aluminium Alloy (BS 1476)
  • Thread : ET NPT BSP BSPT PG
  • Plating : Chrome (CP) Nickel (NP) Tin (TP)

Brass Earth Tags

  • Application : Installed between the gland entry & equipment, provides an earth bond connection
  • Function : Produces an earth bond connection for electrical continuity
  • Material : Brass BS 2870 CZ123 lead
  • Type : With Brass Screws & Washers, Plain Hole
  • Plating : Nickel (NP) Chrome (CP) Zinc (ZP) Tin (TP)
  • Material : Brass
  • Shape : Available in many shapes & thickness in all sizes, can be coated or plated to customers specification as mentioned.

Hexagonal Reducers & Stop Plugs

  • Application : Reducer allows a PG threaded gland to be terminated in enclosures with different entry thread form (ET NPT BSP BSPT)
  • Function : Reduce the entry thread diameter of enclosures
  • Material : Brass BS 2874 CZ121 Pb3
  • Finish : Electro Nickel Plated
  • Thread : Metric (ISO) ET NPT BSP BSPT
  • Plating : Chrome (CP) Zinc (ZP) Tin (TP)
  • Material : Brass Casting BS 2874 Aluminium Alloy & Galvanized Steel
  • Application : Stop Plug may be used to close thread entries or means of sealing & stopping unused thread entries in flame proof enclosures
  • Ingress Protection : IP66 (with Nickel Thread Seal) IP368 (3 bar-with Nitrite 'O' Rings)
  • Options Thread : ET NPT BSP BSPT & PG

PVS Shrouds

  • Application : Push on shrouds which are used to minimize the risk of dirt or foreign substances gathering on the Cable Gland Body, and/or point of cable to a gland interface.
  • Function : For all types of gland applications to provide additional protection & enhances the IP rating of the gland termination.
  • Material : PVC DIP moulded (Black)
  • Operating Temp. : PVC DIP moulded -20°C to +100°C
    Injection moulded -20°C to +80°C

Star Washer

  • Application : The serrated lock washer with external teeth for cable glands
  • Material : Available in Brass & Stainless Steel & Steel
  • Size : From M 20 to M 63
    Can be developed as per the drawing also

Seals & 'O' Rings

  • Application : To maintain the IP rating between equipment & cable glands it may be necessary to fit an entry thread sealing washer at the gland entry interface.
  • Material : Nitrite Rubber & EPDM
  • Options Material : PVC (Black) Silicon (Orange) Polyamide or Nylon (White) Red Fibre.
    Seals available for both external of & internal use.
  • We manufacture other types of Accessories also and according to specifications, drawing and samples. Other Accessories like Cable Ties, Reducers, Enlargers, Adaptors, Converters, and Stopping Plugs.

Copper Ferrules

  • Material : E-Copper-BS : 1977
  • Surface : Tin Plated

Technical Data

CABLE mm2 A C J
1 .5 1.8 3.7 15
22
2.5 2.4 4.0 15
22
4 3.1 4.8 15
25
15
6 3.8 5.5 22
25
20
10 4.5 6.2 22
30
16 5.4 7.1 20
35
25
6.8
8.8		 32
40
47
35 8.2 10.6 36
45
50
9.5
12.4		 40
47
50
40
70 11.2 14.7 45
50
45
95 13.5 17.4 50
60
120 15.0 19.4 45
65
150 16.5 21.2 55
65
185 18.5 23.5 65
75
240 21.0 26.5 80
85
89
300 23.5 30.0 85
90
400 26.8 34.8 90
100
500 30.0 39.0 100
110
630 35.0 45.0 110
120
800 39.0 50.6 150
1000 43.0 56.2 170

Also available in Kit Packaging and also as per the specification

Copper Ferrules

  • Material : E-Copper
  • Surface : Tin Plated

Technical Data

CABLE MM2 A C J
0.5 1.0-1.1 1.4-1.5 6
0.75 1.4-1.5 1.8-1.9 6
1.0 1.6-1.7 2.0-2.1 6
1.6-1.7 2.0-2.1 10
1.5 1.8-1.9 2.2-2.3 7
1.8-1.9 2.2-2.3 10
2.5 2.3-2.4 2.7-2.8 ' 7
2.3-2.4 2.7-2.8 12
4.0 2.8-2.9 3.2-3.3 9
2.8-2.9 3.2-3.3 12
6.0 3.7-3.8 4.1-4.2 10
3.7-3.8 4.1-4.2 12
3.7-3.8 4.1-4.2 15
10 4.6-4.7 5.0-5.1 12
4.6-4.7 5.0-5.1 15
4.6-4.7 5.0-5.1 18
16 5.9-6.0 6.3-6.4 12
5.9-6.0 6.3-6.4 15
5.9-6.0 6.3-6.4 18

Also available in Kit Packaging and also as per the specification

Shapes & Sizes

Tailored to Your Needs: Our size and shape options are completely customizable, meeting your exact specifications. Additionally, we offer a comprehensive range of premium alloys, including Free Cutting Brass, Forging Brass, and Lead-Free Brass, ensuring we meet your unique requirements.

Live Brochure

Explore our dynamic live brochure for an immersive journey through our extensive range of high-quality brass products.

Explore Brochure

Explore Our

Brass Innovations

Brass Rods Sections
CNC Machined Components
Automotive Components & Moulding Inserts
Electrical Components
Brass Cable Glands
Custom Made Components
CNG LPG Accessories
Pneumatic Parts & Flare Fittings
Sanitary Fittings
Brass Fasteners
Earthing & Lightning Protection
Brass Inserts
Forged Machined Components
Brass Nuts
Copper Machined Components
Sheet Metal Stamped Parts

Contact Us

Reach Out and Connect with Us

To Talk To

+91 81288 88877

To Meet

Plot No. 4802/02, Phase-3, G.I.D.C., Dared, Jamnagar - 361004. Gujarat. India.

Write to Each Other

info@gayatrigroups.net

L O A D I N G
